MIR-9000-CLD CEM System

Name(Required)
Preferred Communication Method
Hidden
This field is for validation purposes and should be left unchanged.

Description

Envea have developed a multi-gas continuous emissions monitoring system utilising the Standard Reference Methods (SRM) for the monitoring of NO, N2O, NO2, NOX, CO, CO2 and O2. It also utilises the technology stated in the Alternative Reference Method (ARM) for SO2.

“Three Monitoring Technologies”

The MCERTS certified MIR-9000-CLD emissions analyser is a free-standing on-stack monitoring system that incorporates three monitoring technologies. These are Chemiluminescence for low-level NOx measurement, Infra-Red Gas Filter Correlation for CO, CO2 etc and finally Paramagnetic for O2. This system gives high accuracy at low levels and maximum availability.

Compliance

Designed to operate under Industrial Emissions Directive (IED) legislation. The MIR9000-CLD emissions analyser offers maximum availability and complete compliance with QAL1 of EN14181.

Complete systems would normally comprise of:

  • Sample extraction and conditioning probe (with integrated temperature, pressure and flow measurement)
  • Cold sample lines
  • Automatic calibration units
  • Instrument air drying system
  • Data acquisition & management system

Dual Redundancy System

Under the IED, the maximum period allowed for any one episode of abatement or equipment failure must not exceed four hours. Additionally, the total allowance period for a year must not exceed sixty hours.

The a1-cbiss duplex philosophy has therefore been specifically developed to assist you in complying with IED by reducing downtime, maximising availability and ensuring you achieve a sound return on your investment.

Additional Information

Weight 10 kg
Brand

Configuration

Sensor Type

, ,

Product Downloads
